David Gilmour’s PULSE Live Gear: Guitars, Amps and Effects Behind the Iconic 1994 Tone
Few live guitar sounds are as instantly recognisable as David Gilmour’s tone during Pink Floyd’s 1994 The Division Bell tour, later documented on the PULSE live album and concert film.
The sound was enormous yet articulate, highly processed yet remarkably expressive. It combined clean amplifier headroom, carefully selected drive pedals, stereo modulation, long digital delays and an extremely sophisticated Pete Cornish routing system.
In this guide, we explore the most important guitars, amplifiers, cabinets and effects behind the celebrated PULSE-era live sound.
The PULSE Rig Was a Complete System
Gilmour’s 1994 sound did not come from one amplifier or one “magic” pedal.
It was created by the interaction of several elements:
- Stratocaster-style guitars with active EMG pickups
- Powerful and highly dynamic Hiwatt amplification
- Multiple compressors, fuzzes and overdrives
- Stereo chorus, rotary-speaker effects and modulation
- Programmable digital delays
- Custom Pete Cornish routing and switching
- Gilmour’s distinctive phrasing, vibrato and note control
Pete Cornish’s documentation of the 1994 touring system confirms that the rig contained a large collection of compressors, overdrives, fuzz circuits, modulation effects, digital processors and dedicated routing equipment. The pedals were not simply connected in a conventional series chain: the system was designed to preserve signal quality, control impedance and make a highly complex rig manageable on stage.
The Main Electric Guitar: The Red Stratocaster
Contrary to a common assumption, the famous Black Strat was not the principal guitar of the 1994 tour.
Gilmour’s main electric guitar during The Division Bell tour was his red Fender Stratocaster, equipped with an active EMG system. It was used extensively throughout the tour and can be seen prominently in the PULSE concert film.
The guitar featured:
- EMG SA active single-coil pickups
- EMG SPC mid-boost control
- EMG EXG expansion control
- A maple neck and fingerboard
- A stable, clear and relatively low-noise output
The EMG SA pickups delivered a smoother and more controlled response than many traditional passive Stratocaster pickups. The SPC control could add midrange body, while the EXG circuit could emphasise bass and treble frequencies.
This gave Gilmour a broad tonal range without changing guitars: glassy cleans, compressed rhythm textures and powerful lead sounds could all be produced from the same basic instrument.
The Black Strat remains one of Gilmour’s most historically significant guitars, but an accurate PULSE-era guide should place the red EMG-equipped Stratocaster at the centre of the 1994 electric rig.
Acoustic Guitars and 12-String Textures
The PULSE performances also featured acoustic instruments for songs requiring a more organic and spacious sound.
For material such as “Wish You Were Here,” acoustic and 12-string guitar textures played a major role in recreating the layered character of the original arrangements.
These sounds provided a strong contrast to the huge electric rig. Rather than relying only on processors to imitate acoustic textures, the live production used dedicated instruments suited to each musical section.
Lap Steel and the Sound of “High Hopes”
One of the most memorable instrumental moments from the PULSE era is the lap-steel performance in “High Hopes.”
The lap steel allowed Gilmour to produce long glides, vocal-like transitions and sustained melodic phrases that would feel very different on a conventional fretted guitar.
The instrument’s contribution illustrates a central characteristic of Gilmour’s approach: the choice of equipment always served the musical phrasing. The unusual sound did not come solely from effects; it came from the physical relationship between the slide, the instrument and the player’s control of pitch.
Hiwatt Amplification: Power, Clarity and Headroom
Hiwatt amplifiers were a fundamental part of Gilmour’s live sound.
The Hiwatt DR103 is widely associated with his rigs because of its loud, authoritative clean response and exceptional headroom. Instead of creating the majority of the distortion inside the amplifier, Gilmour could use the Hiwatt as a powerful and relatively clean platform for pedals and external preamps.
This approach offered several benefits:
- Strong note definition
- Excellent dynamic response
- A solid low-frequency foundation
- Enough headroom for fuzz and overdrive pedals
- Clarity when several effects were active
- Reliable projection in large venues
The 1994 system was more complex than a simple guitar-to-Hiwatt setup. Research into the rig also describes the use of an Alembic F-2B-style preamp section in combination with Hiwatt power amplification, creating a customised tonal platform suited to the closed-back cabinets used during that period.
WEM Cabinets and the Live Speaker System
Hiwatt heads were historically paired with WEM speaker cabinets, a combination strongly connected with Gilmour’s large and articulate stage sound.
The speaker system used for the 1994 tour was extensive and could vary according to the stage configuration. The complete live setup also incorporated additional cabinets and rotary-style systems rather than relying on a single conventional amplifier stack.
The goal was not simply maximum volume. The system had to preserve clarity while producing a wide stereo image across very large venues.
Pete Cornish Routing and Switching
The complexity of the PULSE rig would have been extremely difficult to manage with a standard pedalboard.
Pete Cornish designed and modified Gilmour’s touring systems to provide:
- Reliable switching
- Correct impedance matching
- Controlled signal levels
- Reduced noise
- Professional-grade buffering
- Custom effect routing
- Improved durability for touring
Cornish also modified individual effects, replacing or upgrading components where necessary to improve noise performance, reliability and tonal consistency.
The routing system allowed Gilmour to combine different compression, drive, modulation and delay devices without treating the entire rig as one uncontrolled chain of pedals.
This is one of the main reasons the PULSE tone remained detailed despite the considerable amount of processing involved.
Compression: Controlling the Foundation
Compression was an important part of the 1994 signal chain.
Documented components included devices such as the:
- Boss CS-2 Compressor
- MXR Dyna Comp
Compression helped even out the signal, increase sustain and create a more controlled response before the signal reached drive and modulation effects. Pete Cornish’s list of the 1994 rig confirms the presence of the Boss CS-2, while detailed song-by-song reconstructions also identify combinations of CS-2 and MXR compression.
The goal was not to remove all playing dynamics. Instead, compression supported Gilmour’s controlled attack and helped notes remain present through the large live rig.
Fuzz and Overdrive
The sustaining lead sound associated with PULSE was created through several different drive stages.
The documented 1994 system included devices such as:
- Electro-Harmonix Big Muff
- Pete Cornish P-2
- Pete Cornish G-2
- Pete Cornish Soft Sustain / SS-2
- Chandler Tube Driver
- Additional boost and EQ stages
The Sovtek “Civil War”-era Big Muff and the Pete Cornish P-2 were among the important fuzz-style options associated with the tour. These devices delivered a thick, sustaining lead sound with more body and midrange presence than some earlier Muff variations.
The Pete Cornish G-2 offered a more focused and articulate drive character. A Tube Driver or another gain stage could then be used to push, shape or tighten the main distortion sound.
Rather than using the same distortion combination for every solo, Gilmour employed different gain structures according to the song.
Modulation: Chorus, Flanging and Rotary Movement
Modulation contributed significantly to the width of Gilmour’s clean and lead sounds.
The 1994 rig included or employed effects and processors capable of producing:
- Chorus
- Flanging
- Rotary-speaker simulation
- Stereo spatial movement
- Pitch-based widening
Boss CE-2 chorus pedals were used to enhance the stereo spread, while rotary systems and processors added movement and depth to selected sounds.
These effects were generally used to enlarge the guitar rather than make it sound obviously “effected.” The modulation often sat behind the core tone, creating width without destroying the direct attack.
Digital Delay: The Space Around the Notes
Delay is one of the most recognisable components of the Gilmour sound.
During the PULSE era, the rig included professional digital delay equipment such as the:
- TC Electronic 2290
- MXR Digital Delay II
- Roland SDE-series processors
- Additional programmable rack effects
Pete Cornish’s 1994 rig list documents a highly developed collection of delay and processing equipment. Song-by-song studies also show that delay times and effect combinations changed depending on the musical section.
The TC Electronic 2290 was especially useful in a professional touring system because it offered clean, precise and programmable repeats.
Rather than functioning as a simple audible echo, the delay created space around the notes. It helped sustained phrases connect naturally while maintaining rhythmic definition.
A Simplified PULSE-Style Signal Chain
The exact 1994 routing varied by song, and the original system contained parallel paths, switching loops and specialised processors.
However, a simplified version of the tonal architecture can be represented as:
Guitar → Compression → Fuzz or distortion → Overdrive or boost → EQ → Volume control → Modulation → Delay → Clean amp platform
This general order reflects the broader signal-chain approach documented in detailed studies of Gilmour’s rigs.
A modern digital version could therefore begin with:
- A Strat-style guitar model or real Stratocaster
- A light compressor
- A Big Muff-style fuzz
- A mid-focused overdrive or booster
- Corrective EQ
- Subtle stereo chorus or rotary modulation
- A clean digital delay
- A loud, clean British amplifier model
- A suitable 4x12 cabinet or impulse response
- Plate or hall reverb for live ambience
The important point is balance. Adding more gain or more delay does not automatically create a more authentic result.
The PULSE Tone Formula
The fundamental recipe can be summarised as:
1. A clear Stratocaster foundation
The guitar must retain definition, particularly during sustained chords and melodic passages.
2. A loud and clean amplifier platform
The amp provides authority and headroom rather than excessive preamp distortion.
3. Layered gain stages
Fuzz, overdrive, compression and EQ work together instead of relying on one extremely saturated effect.
4. Controlled stereo movement
Chorus and rotary textures create width while preserving the centre of the sound.
5. Precise delay
Repeats should support the rhythm and phrasing rather than cover the original note.
6. Expressive playing
Wide but controlled vibrato, accurate bends, dynamic picking and careful note duration remain essential.
The equipment provides the colours, but the player determines how those colours are used.
How to Recreate the PULSE Sound on a Digital Modeler
Modern digital devices make it possible to reproduce the architecture of this huge touring rig in a much smaller format.
A practical preset should prioritise:
- Clean headroom
- Correct gain staging
- Midrange control
- Stereo modulation
- Tempo-appropriate delay
- Cabinet selection
- Output levelling
- Snapshot or scene-based switching
Different songs require different settings. A clean preset inspired by “Shine On You Crazy Diamond” should not use the same gain and delay structure as a lead preset designed for “Comfortably Numb” or “Sorrow.”
For the best result, each preset should be treated as a complete signal chain rather than a collection of famous pedal names.
Liveplayrock creates ready-to-play guitar presets inspired by iconic rock tones and optimised for the most popular digital guitar devices.
Explore the available collections for:
- Line 6 Helix and HX Stomp
- Fractal Audio systems
- Kemper Profiler
- ToneX
- HeadRush
- Quad Cortex
- BOSS modelers
- Hotone Ampero 2
- Valeton GP200
- Other supported digital platforms
Final Thoughts
David Gilmour’s PULSE sound remains legendary because it combined scale with musical sensitivity.
The rig was technically enormous, but the final tone never felt like a demonstration of equipment. Every compressor, fuzz, amplifier, modulation effect and delay served the phrasing of the music.
The most useful lesson is therefore not simply to copy every component.
Start with a clear guitar tone. Build gain in layers. Preserve dynamics. Use modulation and delay with purpose. Most importantly, allow every note enough space to communicate.
